CNC machining center:

Five-axis linkage machining center is adopted, which is a processing center with high technological content and high precision. The five-axis linkage machining center has the characteristics of high efficiency and high precision. The workpieces can be completed in one setup with complex machining. There are five axes x, y, z, a, and c. The xyz and ac axes form a five-axis linkage process, and specialize in shaped machining. Processing, drilling, hypotenuses, etc.

Horizontal x axis 2440mm,

Vertical y axis 1200mm,

The vertical axis is 750mm

The fastest axis movement speed:

x axis 26m/min

Y axis 60m/min

z axis 15m/min

a axis +/- 100°

C-axis +/- 225°

Double swing head spindle power 7.5KW-15KW

Rotary axis (B.C axis), double supported single drive,

Disc type tool magazine 24, three-dimensional precision measurement

Flatness within 0.02mm,

Accuracy within 0.01mm.
